Description
AIMA E-Bike is proud to present the Big Sur, our first e-bike model. Inspired by the rugged terrain and sweeping vistas of California's Big Sur coastline, infused with a deep appreciation for the beauty of the natural world, and a commitment to cutting-edge engineering, crafted with meticulous attention to detail, AIMA E-Bike is designed in California and manufactured in the world's largest E-Mobility factory. We prioritize safety, performance, aesthetics, and integrity in every step of the manufacturing process, with a mission to deliver you the perfect companion for your next big ride.
Specs
| MOTOR | Rear Hub Motor, BAFANG, 750W Peak Power: 1200W | Max Torque: 85Nm |
|---|---|
| THROTTLE | Throttle on Demand |
| DISPLAY | BAFANG E-system TFT Display Smart Function: FindMy, Navigation, Calls, Notifications |
| CERTIFICATION | UL2849 Compliant |
| SPEED | 20 MPH |
| BATTERY | Removeable Internal Lithium-Ion, 48V, 20Ah (960Wh) |
| LIGHTING | Integrated Headlight, Tail Lights, and Turn Signals w/Horn |
| PEDAL SENSOR | Customizable w/Torque & Cadence Modes |
| PEDAL ASSIST | 5 PAS Levels |
| CHARGER | 48V, 3 Amp Fast Charger, 7-8 Hours to a Full Charge |
| RANGE | 40-75 miles |
| FRAME | 6061 Single-Butted Aluminum Alloy Frame |
| WEIGHT | 82lbs |
| PEDALS | 9/16" Alloy Platform |
| FORK | ZOOM Suspension Fork, 80mm Travel, Adjustable Preload, Lockout |
| PAYLOAD CAPACITY | 400lbs |
| KICKSTAND | Aluminum Alloy Kickstand |
| CRANKSET | 170mm w/ 52T Chainring |
| SHIFTER | Shimano 8 Speed |
| DERAILLEUR | Shimano 8 Speed |
| CASSETTE | 8 Speed, 11-34T |
| BRAKES | Tektro Hydraulic Disc Brakes, 203 mm Rotors |
| CHAIN | 8 Speed |
| RIMS | Double Wall Aluminum Alloy |
| SPOKES | Black Stainless 12G Front / 12G Rear |
| TUBES | Butyl Rubber |
| FRONT HUB | Aluminum Alloy Disc |
| TIRES | 26" x 4.0" |
| SADDLE | AIMA Comfort Saddle |
| SEATPOST | Aluminum Alloy, 30.9mm 2-Bolt Clamp, 300mm |
| STEM | Threadless, 31.8mm, 7° Rise, 75mm Length |
| SEAT CLAMP | 34.9mm Quick Release |
| HANDLEBARS | Aluminum Alloy Double Wall, 31.8mm, 680mm |
| HEADSET | Sealed Bearing Headset |
| GRIPS | Ergonomic Comfort |
Geometry
Product Variants SKU/UPC
- AIMA Big Sur 2.0 E-Bike: Titanium Gray / 26": SKU: 930006-03-L - UPC:
