- Description
- Specs
- Geometry
Gravel riding on more technical terrain. We’ve designed the seatstays to offer unparalleled damping, providing significant comfort and control over technical terrain. And if that isn’t enough for you our top-of-the-line DUSTY RR comes fitted with a 40mm RockShox Rudy fork, and a 75mm Reverb XPLR AXS dropper post so you can take your DUSTY where logic tells you that you really shouldn’t.
Components
Technical specs
-
Frame
Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.
Sizes
S: 440mm / M: 460mm / L: 500mm / XL: 530mm
-
Fork
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Headset
OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Stem
OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S/M: 70mm, size L: 80mm, XL: 90mm
Handlebar
MDK Urban 1.0 double butted 6061 alloy, rise: 0mm, width: 640mm, 9º backsweep, 0º upsweep, 31.8mm barbore
-
Grips
Lizard Skins DSP 30.3
Seatpost
Seatpost with integrated Supernova led rear light, diameter 27.2mm, length 400mm
-
Saddle
Selle Royal Prestige 139mm
Front brake
Sram Level Silver 2P Stealth, 2 piece flatmount caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Rear brake
Sram Level Silver 2P Stealth, 2 piece flatmount caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Level Silver, tools-free reach adjust, lever pivot bearings
-
Rims
MDK-XG1, 25mm internal width, tubeless ready, 28 spokes
Spokes
CN round stainless steel
-
Front hub
Novatec D041, Boost 12x100mm, sealed bearings, IS 6 bolts
Rear hub
Mahle X20 Drive Unit, XDR freehub
-
Front tire
Maxxis Re-fuse 700x40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead
Rear tire
Maxxis Re-fuse 700x40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead
-
Crankset
SRAM Rival 1 GLS Wide, size S: 170mm, size M: 172,5mm, size L: 172,5mm, size XL: 175mm.
Rings
Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,
-
Bottom bracket
Mahle DUB pressfit, sealed bearings, w/ torque sensor
Chain
Sram Rival, 12s, Powerlock
-
Rear derrailleur
Sram Rival XPLR Etap AXS 12s
Shift levers
Sram Rival Etap AXS 12s, X-Actuation 1:1, single click
-
Casette
Sram XG-1251 10-44T, 12s
Derailleur hanger
Mondraker M076
-
Others
Front light: 150LUX output DC 6-12V, waterproof Alloy cage. Optional external battery: Mahle e185Wh
Weight
30,9 lbs
-
Display
Pulsar One Wireless
Motor
Mahle X20 Drive Unit
-
Battery
Mahle X20 IX350Wh
| Frame size | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Seattube length | 440 mm 17.32" | 460 mm 18.11" | 500 mm 19.69" | 530 mm 20.87" |
| B | Toptube length | 550 mm 21.65" | 570 mm 22.44" | 595 mm 23.43" | 620 mm 24.41" |
| C | Bottom bracket drop | 70 mm 2.76" | 70 mm 2.76" | 70 mm 2.76" | 70 mm 2.76" |
| D | Bottom bracket height | 286 mm 11.26" | 286 mm 11.26" | 286 mm 11.26" | 286 mm 11.26" |
| E | Chainstay length | 425 mm 16.73" | 425 mm 16.73" | 425 mm 16.73" | 425 mm 16.73" |
| F | Seat tube angle | 74º | 74º | 74º | 74º |
Product Variants SKU/UPC
- 2025 Mondraker Dusty RX: Red / Grey / SM: SKU: MO-010-25US407 - UPC:
- 2025 Mondraker Dusty RX: Red / Grey / MD: SKU: MO-010-25US408 - UPC:
- 2025 Mondraker Dusty RX: Red / Grey / LG: SKU: MO-010-25US409 - UPC:
- 2025 Mondraker Dusty RX: Red / Grey / XL: SKU: MO-010-25US410 - UPC:
