This product is available for in-store pickup only.
The Tallboy is a short-travel bike with long legs. Our perennial 29-inch bike has gone on a diet and bulked up the amount of travel to fit the kind of rider looking to maximize power hours or just ride all the hours. It’s light and efficient enough to climb with the best of them, yet punches way above its weight class as soon as the trail turns down. Excellent suspension, big wheels, thoroughly-tuned carbon layup and rock-solid reliability let you go as hard as you want.
Frame
Carbon CC 29" 130mm Travel 4-Bar
Travel (mm)
130mm
Frame Material
Carbon CC
Wheel Size
29"
Weight
30.79 lbs / 13.97 kg
Battery Charger
n/a
Bottom Bracket
SRAM DUB 73mm MTB Wide BB
Brakes
SRAM DB8
Cassette
SRAM XS 1275 Eagle T-Type, 10-52t
Chain
SRAM GX Eagle T-Type, Flattop, 12spd
Chainguide
OneUp Chainguide
Crankset
SRAM 90 Eagle DUB T-Type, 32t
XS-S: 165mm, M-XXL: 170mm
Fork
RockShox Pike Select, 140mm
Front Hub
DT Swiss 370, 15x110, 6-Bolt, 28h
Front Rim
Reserve 30|TR AL
Front Rotor
SRAM HS2 200mm
Front Tire
Maxxis Forekaster 29"x2.4", MaxxTerra, EXO
Grips / Bar Tape
Santa Cruz Bicycles House Grips
Handlebars
OneUp Aluminum Bar, 35mm
XS-M: 760mm, 20mm Rise, L-XXL: 800mm, 35mm Rise
Headset
Cane Creek 50 IS Integrated Headset
Rear Derailleur
SRAM 90 Eagle T-Type, 12spd
Rear Hub
DT Swiss 370, 12x148, XD, 6-Bolt, 36t, 28h
Rear Rim
Reserve 30|TR AL
Rear Rotor
SRAM HS2 180mm
Rear Shock
RockShox Deluxe Select+, 185x50
Rear Tire
Maxxis Forekaster 29"x2.4", MaxxTerra, EXO
Right Shifter
SRAM 90 Eagle T-Type, 12spd
Saddle
SDG Bel-Air V3 Lux-Alloy
Seatpost
OneUp Dropper Post, 31.6
XS: 120mm, S: 150mm, M: 180mm, L-XL: 210mm, XXL: 240mm
Stem
OneUp Enduro Stem
All Sizes: 42mm
Valves
Reserve Fillmore Valves
Headset Headtube
Integrated (IS41/52)
Fork Axle To Crown
554
Fork Offset
44
Fork Compatibility
140-150
Suspension System
4-Bar
Rear Travel
130mm
Recommended Sag
30%
Eye To Eye Length
185
Stroke
50
Shock Mounting Hardware Upper
Trunnion
Shock Mounting Hardware Lower
25x8
Bb Shell
73mm Threaded
Chainline
55
Max Chainring Size
34
Chainguide Standard
Integrated upper guide
Derailleur Hanger
UDH
UDH Compatible
Yes
Rear Spacing
148mm
Brake Mount
Postmount 180mm
Max Rotor Size
203mm
Max Tire Size
2.4"
Seatpost Diameter
31.6
Seat Clamp
36.4
Water Bottle Mounts
1
Downtube Storage
Glovebox
Rear Brake Mount
180mm
Specifications are subject to change.
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Reach (Hi/Lo) | 410/407 | 435/432 | 455/452 | 475/472 | 495/492 | 520/517 |
| Stack (Hi/Lo) | 601/603 | 610/612 | 624/626 | 633/635 | 646/649 | 660/662 |
| Head Tube Angle (Hi/Lo) | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° |
| Head Tube Length | 90 | 100 | 115 | 125 | 140 | 155 |
| Rear Center (Hi/Lo) | 435/435.5 | 435/435.5 | 435/435.5 | 438/438.5 | 440/440.5 | 444/444.5 |
| Front Center (Hi/Lo) | 721/721 | 750/750 | 777/776 | 801/801 | 827/827 | 858/858 |
| BB Height (Hi/Lo) | 336/333 | 336/333 | 336/333 | 336/333 | 336/333 | 336/333 |
| BB Drop (Hi/Lo) | 36/39 | 36/39 | 36/39 | 36/39 | 36/39 | 36/39 |
| Wheelbase (Hi/Lo) | 1156/1156 | 1185/1186 | 1212/1212 | 1239/1239 | 1267/1267 | 1302/1303 |
| Top Tube Length (Hi/Lo) | 542/542 | 569/570 | 596/596 | 616/616 | 637/638 | 666/666 |
| Seat Tube Length (Hi/Lo) | 360/370 | 380/380 | 400/400 | 420/430 | 450/450 | 500/500 |
| Seat Tube Angle (Hi/Lo) | 77.6°/77.3° | 77.6°/77.3° | 77.3°/77° | 77.4°/77.2° | 77.5°/77.3° | 77.5°/77.3° |
| Seat Tube Angle at Saddle Height (Hi/Lo) | 77.4/77.1 at 640 | 77/76.8 at 680 | 76.5/76.3 at 730 | 76.5/76.3 at 780 | 76.5/76.3 at 830 | 76.5/76.3 at 870 |
| Standover Height (Hi/Lo) | 699/695 | 703/699 | 718/714 | 728/725 | 742/739 | 758/755 |
