2025 Norco Storm 120

By Norco Bikes Canada
$1,099.00 CAD

In stock at supplier warehouse - Usually ships within 5 business days. More info

0672015754
Color: Nanaimo Bar
Size
View details
Description
2025 Storm 120

The Storm 120 features a progressive off-road design and features that’ll help you discover your favourite way to ride.

The Storm 120 opens up the world of off-road adventure.

It’s built for off-road adventure, but the lightweight aluminum Storm 120 is more than happy to lead a double life on city streets and park paths.

Details
Specs

Frame Aluminum, Smooth Welding, 10x135mm QR, Tapered HT
Fork SR Suntour XCM32LO w/ lockout, 120mm, 46mm offset, 15x100mm
Rear Shifter Shimano Cues SL-U6000-10R, 10sp
Rear Derailleur Shimano Cues RD-U6000, 10sp, GS
Crankset Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL)
Bottom Bracket Cartridge, ST 73mm, 113mm axle length
Cassette Shimano Cues CS-LG300-10, 11-48T, 10sp
Chain KMC Cues XGlide 9/10/11
Front Brake Tektro HD-M275, Resin pads
Front Brake Rotor Tektro. 160mm, 6-bolt
Rear Brake Tektro HD-M275, Resin pads
Rear Brake Rotor Tektro. 160mm, 6-bolt
Brake Levers Tektro HD-M275
Handlebar 6061 Alloy DB, 750mm (S) / 780mm (M,L,XL,XXL) 30mm rise
Stem Alloy 50mm Length, 31.8mm Clamp
Seatpost X-Fusion Manic LC, 31.6mm, 100mm (S), 125mm (M,L/XL/XXL)
Headset Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 )
Headset Spacer 3x10mm
Saddle Norco XC, Steel Rail
Grips DDK lock-On, 139mm length
Pedals Nylon Flat Pedal
Seatpost Clamp Norco Alloy QR, 34.9mm ID
Front Hub Formula DC51 , 15x100mm, 32h, 6-bolt
Rear Hub Formula DC-1422,10x135mm QR, HG, 32h, 6-bolt
Rims DP 27 Rims, 27mm ID, 32H
Front Tire Maxxis Forekaster, 29x2.25" (27.5X2.25"size S), Wire
Rear Tire Maxxis Forekaster, 29x2.25" (27.5X2.25"size S), Wire
Spokes/Nipples Stainless Steel, 14g
Weight 14.59 kg (32.1 lbs)
Weight Size L



Geometry
S M L XL XXL
Wheel Size 27.5" 29" 29" 29" 29"
Travel (mm front) 120
Reach 410 440 470 500 530
Stack 608 628 637 646 655
HTA Head Tube Angle 67
OS Fork Offset 42 46
ST Seat Tube Length 430 470 510 550 590
STA Effective Seat Tube Angle 74.5 74.75 75 75.25 75.5
RC Rear Centre Length 430 440
BB Bottom Bracket Drop 32 52
BBH Bottom Bracket Height 321
HTT Horizontal Top Tube 579 611 641 670 699
WB Wheelbase 1129 1171 1205 1239 1273
SOH Standover 646 671 718 738 769
HT Head Tube Length 125 105 115 125 135
Trail 104 108
Recommended Seatpost Drop 100
Maximum Post Insertion 300 265 300 340 380
Stem Length 50
Crank Length 170 175
Tire Size 2.2" – 2.4"
Water Bottle Compatible 1 x 620 mL 1 x 620mL and 1 x 750 mL 2 x 750 mL
Product Variants SKU/UPC
  • 2025 Norco Storm 120: Nanaimo Bar / SM (27.5): SKU: 0672015754 - UPC: 058817717642
  • 2025 Norco Storm 120: Nanaimo Bar / MD (29): SKU: 0672015955 - UPC: 058817717659
  • 2025 Norco Storm 120: Nanaimo Bar / LG (29): SKU: 0672015956 - UPC: 058817717666
  • 2025 Norco Storm 120: Nanaimo Bar / XL (29): SKU: 0672015957 - UPC: 058817717673
  • 2025 Norco Storm 120: Nanaimo Bar / XXL (29): SKU: 0672015958 - UPC: 058817717680
