2026 BMC Kaius 01 Frameset

By BMC
$6,299.00 CAD

This product is only available for in-store pickup.

In stock at supplier warehouse - Usually ships within 5 business days. More info

30006877
Color: Stone Grey
Size
View details
Specs
Frameset

Frame:
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | UDH Dropout (Universal Derailleur Hanger) | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle

Fork:
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle


Seat

Seatpost:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible


Accessories

In the Box:
Aerocore Bottle Cages | SRAM UDH hanger | High and low ICS top cones, 3x10mm spacers , 2x3mm spacers)
Additional Information

Tire Clearance:
44mm

Weight without Pedals:
1.8 Kg | including headset, bottle cages and hardware

ASTM Classification:
Level 2

System Weight Limit:
120kg



Geometry



Size 47 51 54 56 58 61
Rider Height <166 166-174 172-180 178-186 184-192 >190
Reach 390 397 401 405 410 414
Stack 510 530 550 570 595 620
BB Drop 80 80 80 80 80 80
Crank Length 170 170 172.5 172.5 175 175
Fork Length 387 387 387 387 387 387
Fork Rake 50 50 45 45 45 45
Front Center 596 610 608 619 632 644
Head Tube 85 106 123 144 170 196
Head Tube Angle 71 71 72 72 72 72
Rear Center 420 420 420 420 420 420
Seat Angle 73 73 73 73 73 73
Seat Tube 428 452 468 493 513 533
Seatpost Length 280 320 360 360 400 400
Seatpost Offset 15 15 15 15 15 15
Standover Height 684 722 756 780 798 818
Top Tube 546 559 569 579 592 604
Trail 68 68 68 68 68 68
Wheelbase 1003 1017 1015 1026 1039 1051
Product Variants SKU/UPC
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 47: SKU: 30006877 - UPC:
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 51: SKU: 30006878 - UPC:
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 54: SKU: 30006879 - UPC:
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 56: SKU: 30006880 - UPC:
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 58: SKU: 30006881 - UPC:
  • 2026 BMC Kaius 01 Frameset: Stone Grey / 61: SKU: 30006882 - UPC:
