Frame
F-Podium 29 Stealth Air Full Carbon, XCO Optimized Zero Suspension System, 110mm, XC Forward Geometry, Carbon Monoblock upper link, BSA bottom bracket, tapered head tube, HHG internal cable routing, dedicated 1X drivetrain design, Boost 12x148mm rear axle, UDH, shock mudguard, postmount rear brake mount.
Sizes
S: 410mm / M: 440mm / L: 470mm / XL: 500mm
Rear shock
RockShox SID Luxe Ultimate Flight Attendant, 165x45mm. Settings: Extl rebnd, E-cont. 3 pos comp (open/pedal/lock). Trunnion top mount, 30x8mm bottom bushings
Shock settings
R57 rebound, C30 compression, 1 Token
Fork
RockShox SID Ultimate Flight Attendant, 120mm, Debon Air+, Charger Race Day 2, tapered steerer tube, Boost 15x110mm axle, 35mm tapered aluminum stanchions, offset 44mm. Settings: Extl rebnd, E-cont. 3 pos comp (open/pedal/lock)
Fork remote
Flight Attendant controlled
Headset
Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs with blocklock
Stem
Onoff S6 6061 T6 Alloy + CNC, 31.8mm barbore, rise: -7º, length: S size: 50mm, M size: 50mm, L size: 60mm, XL size: 70mm
Handlebar
Onoff S6 Carbon 0.2, rise: 5mm, width: 760mm, 8º backsweep, 4º upsweep, 31.8mm barbore
Grips
Ergon GXR black
Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 2-BY Remote lever, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), L size: 180-155mm (468-275mm), XL size: 210-185mm (528-305mm)
Saddle
Fizik Vento Argo X5 140mm
Front brake
Sram Motive Silver 4P Stealth, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Sram Motive Silver 4P Stealth, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Motive Silver, tools-free reach adjust, lever pivot bearings
Rims
Mavic Crossmax S Carbon 29, 30mm internal width, hookless, tubeless ready, 24/28 spokes
Spokes
Mavic round J-bent stainless steel
Front hub
Mavic hub, Boost 15x110mm, IS 6 bolts
Rear hub
Mavic hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, XD freehub
Front tire
Maxxis Rekon Race 29x2.4, EXO protection, tubeless ready, 120TPI, folding bead
Rear tire
Maxxis Rekon Race 29x2.4, EXO protection, tubeless ready, 120TPI, folding bead
Crankset
Sram X0 Eagle T-Type, Power Meter, Boost, DUB axle, Direct mount chain ring, S size: 165mm, M size: 165mm, L size: 170mm XL size: 170mm, CL 55
Rings
34T, CNC-machined alloy, T-Type
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram GX Eagle, 12s Flattop, Powerlock
Rear derrailleur
Sram X0 Eagle AXS T-Type,12s
Shift levers
Sram Eagle AXS Pod, 12s
Casette
Sram XS-1275, 10-52T, 12s
Weight
12,2 kg
