Frame
F-Trick 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, 12x148mm rear axle, UDH, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design.
Sizes
One size: 300mm
Rear shock
X-Fusion 02PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock settings
A-Tune light compression
Fork
X-Fusion Slant RC 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset
Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
Stem
Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips
Onoff Beehive, 1lock-on, 135mm
Seatpost
X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 100mm
Saddle
SDG Fly JR
Front brake
Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Rear brake
Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Brake lever
Shimano MT501, servo wave, alloy lever
Rims
MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Front hub
DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub
DA207R 12x148mm, cup & cone ball bearings, IS 6 bolts, HG freehub
Front tire
Maxxis Minion DHF 24x2.4, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead
Rear tire
Maxxis Minion DHR II 24x2.3, Tubeless ready, EXO Protection, 60TPI, folding bead
Crankset
Prowheel DMJ-CR094S-TT, Direct mount chainring, 150mm
Rings
30T, steel
Bottom bracket
Prowheel PW-MBB73 73mm
Pedals
SDG Slater JR
Chain
Sram S100 Eagle, 12s, PowerLock
Rear derrailleur
Sram S200 Eagle,12s
Shift levers
Sram Trigger S100, 12s, X-Actuation
Casette
Sram PG-1210, 11-50T, 12s
Derailleur hanger
UDH
Weight
13,8 kg
