Frame
Podium 29 Stealth Air Carbon, XC Forward Geometry, BSA bottom bracket, tapered head tube, HHG internal cable routing, Boost 12x148mm rear axle, UDH, dedicated 1X drivetrain design, Flatmount brake compatible,
Sizes
S: 390mm / M: 420mm / L: 470mm / XL: 510mm
Fork
RockShox SID SL Ultimate Flight Attendant, 100mm, Debon Air+, Charger Race Day 2, tapered steerer tube, Boost 15x110mm axle, 32mm aluminum stanchions, offset 44mm. Settings: Extl rebnd, E-cont. 3 pos comp (open/pedal/lock)
Fork remote
Flight Attendant controlled
Headset
Onoff IS42/IS52, 1-1/8", 1.5" head tube, sealed bearings
Stem
Onoff S9 Integrated Carbon Handlebar, width: 760mm, 8º Backsweep, 0º Upsweep, S size: 55mm length -12º rise, M size: 55mm length -12º L size: 65mm length -14º rise, XL size: 75mm length -15º rise
Grips
Ergon GXR black
Seatpost
Onoff S9 Carbon 0-R, diameter 27.2mm, length 400mm
Saddle
Fizik Vento Argo 00 Carbon 140mm
Front brake
Sram Motive Ultimate 4P Stealth, 2 piece caliper, HS2 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Sram Motive Ultimate 4P Stealth, 2 piece caliper, HS2 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Motive Ultimate, tools-free reach adjust, lever pivot bearings, carbon lever
Rims
Mavic Crossmax Ultimate Carbon 29 Boost 30mm internal width, hookless, tubeless ready, 20 spokes
Spokes
Mavic 20 straight-pull carbon spokes
Front hub
Mavic MX1001 Ultraligth hub, Ceramic bearing Boost 15x110mm, IS 6 bolts
Rear hub
Mavic MX1001 Ultraligth hub, ID360 freewheel technology, Ceramic bearing, Boost 12x148mm, IS 6 bolts, XD freehub
Front tire
Maxxis Aspen ST 29x2.40, Maxx Speed, EXO protection, tubeless ready, 170TPI, folding bead
Rear tire
Maxxis Aspen ST 29x2.40, Maxx Speed, EXO protection, tubeless ready, 170TPI, folding bead
Crankset
Sram XX SL Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S size: 165mm, M size: 165mm, L size: 170mm XL size: 170mm, CL 55
Rings
34T, CNC-machined alloy, T-Type 8t
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram XX SL Eagle T-Type, 12s Flattop, Powerlock
Rear derrailleur
Sram XX SL Eagle AXS, T-Type, 12s
Shift levers
Sram Eagle AXS Pod Ultimate, 12s
Casette
Sram XS-1299, 10-52T, T-Type, 12s
Weight
8,5 kg
| Frame size | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Seattube length | 390 mm | 420 mm | 470 mm | 510 mm |
| B | Toptube length | 590 mm | 611mm | 632 mm | 650 mm |
| C | Bottom bracket drop | -65 mm | -65 mm | -65 mm | -65 mm |
| D | Bottom bracket height | 300 mm | 300 mm | 300 mm | 300 mm |
| E | Chainstay length | 430 mm | 430 mm | 430 mm | 430 mm |
| F | Seat tube angle | 73° | 73° | 73° | 73° |
| G | Effective seattube angle | 74.5° | 74.5° | 74.5° | 74.5° |
| H | Headtube angle | 68,5° | 68,5° | 68,5° | 68.5° |
| I | Fork Offset | 44 mm | 44 mm | 44 mm | 44 mm |
| J | Wheelbase | 1107 mm | 1128 mm | 1150 mm | 1170 mm |
| K | Headtube length | 85 mm | 90 mm | 100 mm | 115 mm |
| L | Reach | 425 mm | 444 mm | 463 mm | 477 mm |
| M | Stack | 598 mm | 602 mm | 611 mm | 625 mm |
