Frame
Zendit Stealth Air Carbon front triangle, Stealth Alloy rear triangle, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock
RockShox Super Deluxe Select, 205x65mm, Trunnion top mount, 30x8mm bottom bushings
Shock settings
C34 compression, R55 rebound, 4 tokens, X25 lockout force
Fork
RockShox ZEB Base 29, Delta RC, 170mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: low-speed compression, Extl rebound, air preload
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, without blocklock.
Stem
Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore
Handlebar
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost
X-Fusion Manic TA, Travel adjust, diameter 31.6mm,1X Remote lever, S size: 361x125mm, M size: 425x150mm), ML size: 469x170mm, L size: 532x200, XL size: 532x200
Saddle
Ergon SM10 E-Mountain Black.
Front brake
Sram Maven Base, 18-millimeter 4 piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads.
Rear brake
Sram Maven Base, 18-millimeter 4 piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads.
Brake lever
Sram Maven Base , Directlink and lever pivot bushings, tools-free reach adjust
Rims
Mavic E-Access XR30, aluminium, 30mm internal width, tubeless ready, 32 spokes
Spokes
Mavic Reinforced spokes lacing
Front hub
Mavic, Boost 15x110mm, IS 6 bolts
Rear hub
Mavic hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, HG reinforced freehub
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead
Rear tire
Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead
Crankset
E.13 Helix Core E*Spec Plus, All sizes: 155mm
Rings
Sram Eagle 36T T-Type, 104BCD, steel, CL55
Chain
Sram 70 T-Type, 12s Flattop, PowerLock
Rear derrailleur
Sram 70 Eagle, T-Type, 12s
Shift levers
Sram Trigger 70, 12s, T-Type Actuation
Casette
Sram XS-1270, 10-52T, 12s
Display
Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
Motor
Avinox M2S
Battery
Avinox 800Wh Battery / Avinox 4A Charger
