2027 Mondraker Zendit XR

By Mondraker
$17,999.00 CAD
MO-010-27US211
Color: Vortex Grey
Size
View details
Description

the flagship Mondraker e-MTB that boasts a new level of performance, achieved from the latest frame design and ZERO suspension kinematics, with seamless integration of the powerful new Avinox M2S drive system.

  • Rear shock · Fox Float X2 Factory Kashima
  • Fork · Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm
  • Front brake · Sram Maven Ultimate
  • Motor · Avinox M2S Drive Unit
  • Battery · Avinox 800Wh Battery / Avinox 12A Charger


Technical specs
  • frame

    Frame

    Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

           sizes

    Sizes

    S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
  • rear shock

    Rear shock

    Fox Float X2 Factory Kashima 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.

           shock settings

    Shock settings

    CS 30 compression, 1,1 Bleed, RS40 rebound, Rezi B40, LML, Long MCU, 0 volume spacers.
  • fork

    Fork

    Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.

           headset

    Headset

    Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, without blocklock.
  • stem

    Stem

    Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.

           handlebar

    Handlebar

    Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
  • grips

    Grips

    Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size.

           seatpost

    Seatpost

    RockShox Reverb AXS, diameter 31.6mm, w/AXS Pod Controller Rocker Paddle. S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm.
  • saddle

    Saddle

    Ergon SM10 E-Mountain Black.

           front brake

    Front brake

    Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
  • rear brake

    Rear brake

    Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

           brake lever

    Brake lever

    Sram Maven Ultimate , Carbon lever, SwingLink and lever pivot bearings, tools-free reach adjust
  • rims

    Rims

    DT Swiss Hybrid HXC 1500 Spline, Carbon, 30mm internal width, tubeless ready, 28 spokes.

           spokes

    Spokes

    DT Swiss Straightpull spokes, DT Hybrid II, black
  • front hub

    Front hub

    DT Swiss 350, 20x110mm Boost, Disc IS (6-bolt).

           rear hub

    Rear hub

    DT Swiss 350 Classic with 72T Ratchet DEG System, Boost 12x148mm, IS 6 bolts, XD freehub
  • front tire

    Front tire

    Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DD protection, 120x2TPI, folding bead

           rear tire

    Rear tire

    Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead
  • crankset

    Crankset

    e*thirteen Helix Race Carbon e*spec. All sizes: 155mm

           rings

    Rings

    Sram Eagle 36T T-Type, 104BCD, steel, CL55
  • chain

    Chain

    Sram GX Eagle T-Type, 12s Flattop, w/Powerlock

           rear derrailleur

    Rear derrailleur

    Sram X0 Eagle AXS T-Type, 12s
  • shift levers

    Shift levers

    Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s

           casette

    Casette

    Sram XS 1275, 10-52T, T-Type, 12s
  • others

    Others

    Sram AXS Extension Cord / Avinox 12A Charger

           weight

    Weight

    23.1 Kg
  • display

    Display

    Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)

           motor

    Motor

    Avinox M2S
  • battery

    Battery

    Avinox 800Wh Battery

 Geometry

  Frame size S M M/L L XL
A Seattube length 380mm 410mm 435mm 460mm 490mm
B Toptube length 586mm 606mm 628mm 650mm 672mm
C Bottom bracket drop 6mm 6mm 6mm 6mm 6mm
D Bottom bracket height 345mm 345mm 345mm 345mm 345mm
E Chainstay length 450mm 450mm 450mm 455mm 455mm
F Seat tube angle 73.5° 73.5° 73.5° 73.5° 73.5°
G Effective seattube angle 77° 77° 77° 77° 77°
H Headtube angle 63.5° 63.5° 63.5° 63.5° 63.5°
I Fork Offset 44mm 44mm 44mm 44mm 44mm
J Wheelbase 1241mm 1261mm 1286mm 1315mm 1339mm
K Headtube length 110mm 110mm 120mm 130mm 140mm
L Reach 440mm 460mm 480mm 500mm 520mm
M Stack 631mm 631mm 640mm 649mm 658mm
N Stem Length null null null null null
O Fork Height null null null null null
Product Variants SKU/UPC
  • 2027 Mondraker Zendit XR: Vortex Grey / SM: SKU: MO-010-27US211 - UPC: 624316183303
  • 2027 Mondraker Zendit XR: Vortex Grey / MD: SKU: MO-010-27US212 - UPC: 624316183310
  • 2027 Mondraker Zendit XR: Vortex Grey / M/L: SKU: MO-010-27US213 - UPC: 624316183327
  • 2027 Mondraker Zendit XR: Vortex Grey / LG: SKU: MO-010-27US214 - UPC: 624316183334
  • 2027 Mondraker Zendit XR: Vortex Grey / XL: SKU: MO-010-27US215 - UPC: 624316183341
  • 2027 Mondraker Zendit XR: Admiral Blue / SM: SKU: MO-010-27US216 - UPC: 624316183358
  • 2027 Mondraker Zendit XR: Admiral Blue / MD: SKU: MO-010-27US217 - UPC: 624316183365
  • 2027 Mondraker Zendit XR: Admiral Blue / M/L: SKU: MO-010-27US218 - UPC: 624316183372
  • 2027 Mondraker Zendit XR: Admiral Blue / LG: SKU: MO-010-27US219 - UPC: 624316183389
  • 2027 Mondraker Zendit XR: Admiral Blue / XL: SKU: MO-010-27US220 - UPC: 624316183396
