Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | 120mm Travel | FORM™ Alloy Rear Triangle
Fork
Manitou J Unit Comp 120mm | TPC Damper | 20 = 40mm Offset
Front Travel
120
Shock
RockShox Deluxe Select | Sealed Bearing Eyelet | 20x8mm F Hardware | 170x35mm
Rear Travel
120
Headset
FSA Orbit NO.57B | 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Handlebar
Rocky Montain Jr | 600mm Width | 25mm rise | 9° Backsweep | 5° Upsweep | 31.8 | For 19mm Grips
Grips
SGD Slater JR Lock On
Brakes
Tektro HD-J2820 | Short Reach Lever | Shimano Pad Compatible
Shifters
MicroShift Advent Short Reach 9spd
Rear Derailleur
MicroShift Advent Super Short 9spd W/Clutch
Cranks & Chainring
Rocky Mountain Microdrive 2PC | 28T | 104mm Asymmetrical BCD | 24mm Spindle | Crank Length = 127mm
Cassette
SunRace CSM98 11-36T
Chain
KMC X9
Front Hub
Shimano TC500 | 15mm Boost
Rear Hub
Shimano TC500 Boost 148mm
Spokes
2.0 Stainless
Rims
WTB KOM Team i25 TCS 2.0 | 28H |
Tires
Kenda Regolith 20 x 2.4 | Kenda Regolith 20 x 2.4 |
Seatpost
X Fusion Manic Composite 30.9mm | 80mm
Saddle
Rocky Mountain Kids
Weight
This information isn't available yet. We will update the weight of this model as soon as possible.
Notes
We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
