2026 Polygon Xtrada 6

By Polygon
$1,099.00 CAD
503536001
Color: Charcoal Black
Size
View details
Description

XTRADA: Fast. Light. Endlessly Versatile

Cross-Country | 120mm Travel | ALX Alloy | 29" or 27.5" Wheels

Whether taking on the local singletrack or heading out to the hills, the XTRADA is ready for mountain bike adventures. It features a dependable alloy frame, 120mm suspension fork and trail-ready components that we have carefully selected to ensure maximum value without breaking the bank.
Technical Specifications

Frameset

  • Frameset: ALX XC 29
  • Fork: X-FUSION MIGO LO DAMPER 32 120mm TRAVEL BOOST THRU AXLE
  • Frame Color: CHARCOAL BLACK
  • Decal Color: RED BLACK

Drivetrain

  • Shifter: SHIMANO DEORE SL-M6100 1x12-SPEED TRIGGER
  • Crank: SAMOX RAC61C-018S-C55 32T
  • Cassette: SHIMANO CS-M6100 12-SPEED 10-51T
  • Rear Derailleur: SHIMANO DEORE RD-M6100 DIRECT ATTACH
  • BB: SAMOX 2-PIECE CRANKSET BSA THREADED
  • Chain: KMC X-12
  • Pedal: ONE PIECE PP BODY

Cockpit

  • Saddle: LINC VOID SADDLE, STEEL ø7mm
  • Seatpost: DROPPER POST 150mm TRAVEL, DXL: 30.9 x 429mm, SEAT CLAMP: 34.9mm BOLT TYPE
  • Handlebar: POLYGON SPORT ALLOY, W: 760mm, BB: 31.8mm, R/D: 20mm, B: 9degree
  • Handlestem: POLYGON SPORT ALLOY, EXT: 40mm, BB: 31.8mm, R/D: 7degree
  • Headset: ZERO STACK W/ CAGED BEARING, ZS 44/28.6 | ZS 56/40

Wheel & Tire

  • Wheel Set: ALLOY WHEELS
  • Tire: WTB TRAIL BOSS 29"X2.25"
  • Rim: F: ALLOY DOUBLE WALL H:19mm W: 23mm 32H FOR TYRE 622-68 / R: ALLOY DOUBLE WALL H:19mm W: 23mm 32H FOR TYRE 622-68
  • Hub: F: SHIMANO HB-TC500 THRU AXLE 15x110mm 32H CENTERLOCK / R: SHIMANO HB-TC500 THRU AXLE 12x148mm 32H CENTERLOCK FOR MICROSPLINE
  • Spokes: F: 14G STAINLESS NDS: 294mm DS: 292mm 12MM NIPPLE BRASS / R: 14G STAINLESS NDS: 292mm DS: 290 12MM NIPPLE BRASS

Brake

  • Brake Lever: SHIMANO BL-MT200
  • Brake Caliper: SHIMANO MT200 HYDRAULIC DISC BRAKE
  • Rotor: SHIMANO SM-RT10 F: 180mm R: 160mm CENTERLOCK
Geometry
S M L XL
Height (cm) 152-165 162-175 172-185 182-195
Seat Tube Length (A) 390 430 450 470
Seat Tube Angle (B) 73 73 73 73
Effective Seat Tube Angle (C) 74 74 74 74
Head Tube Length (D) 91 100 110 120
Head Tube Angle (E) 67 67 67 67
Effective Top Tube (F) 586 609 632 655
Bb Height (G) 313 313 313 313
Bb Offset (H) 60 60 60 60
Chainstay Length (I) 432 432 437 437
Wheelbase (J) 1121 1145 1174 1198
Frame Reach (K) 410 430 449 470
Frame Stack (L) 620 629 638 647
Standover Height (M) 725 756 771 788
Product Variants SKU/UPC
  • 2026 Polygon Xtrada 6: Charcoal Black / SM: SKU: 503536001 - UPC:
  • 2026 Polygon Xtrada 6: Charcoal Black / MD: SKU: 503536002 - UPC:
  • 2026 Polygon Xtrada 6: Charcoal Black / LG: SKU: 503536003 - UPC:
  • 2026 Polygon Xtrada 6: Charcoal Black / XL: SKU: 503536004 - UPC:
